D2SW-3L2HS by omron electronics

D2SW-3L2HS

Omron Electronics

Switch Snap Action N.O./N.C. SPDT Hinge Roller Lever 3A 250VAC 30VDC 0.59N Screw Mount Solder ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The OMRON Electronics D2SW-3L2HS is a compact and versatile switch that is designed with high performance in mind. It features a snap action mechanism, making it highly responsive and reliable. This switch has a single-pole double-throw (SPDT) configuration, allowing it to have both normally open (N.O.) and normally closed (N.C.) contact positions. The hinge roller lever design ensures smooth and precise actuation, making it suitable for various applications. With a maximum current rating of 3A and a voltage rating of 250VAC or 30VDC, this switch is capable of handling a wide range of electrical loads. Installation is made easy with the screw mount or solder options, allowing for convenient integration into your circuit board or equipment. Additionally, the D2SW-3L2HS switch is lightweight and compact, making it ideal for space-constrained applications. Overall, the OMRON Electronics D2SW-3L2HS switch provides reliable performance, flexibility, and easy installation, making it a great choice for your electrical switching needs.

Search Keywords: D2SW3L2HS

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Omron Electronics
Part No:
D2SW-3L2HS
RoHS:
Yes
HTS:
8536509040
COO:
JP
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
500
Mounting:
Through Hole
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Polyacetal/Stainless Steel/Hinge Roller Lever
Contact Rating @ Voltage:
3@125VAC 30VDC@(CSA/UL) A
Maximum Movement Differential:
0.8 mm
Operating Force:
0.59 N
Termination Style:
Solder
Dimension:
22.05 x 6.4 x 26.6 mm
Body Orientation:
Straight
IP Rating:
IP67

IN STOCK: 2,254

Ships today, if you order in

Minimum Order: 5

Factory Lead-Time 26 Weeks

Price (CAD)

Qty
Unit Price
5
$6.033
50
$4.824
100
$4.762
250
$4.747
500
$4.716
1,000
$4.701
2,500
$4.671
5,000 +
$4.655
