G5LE-1-E-DC12 by omron electronics

G5LE-1-E-DC12

Omron Electronics

Power Relay 12VDC 16A SPDT (22.5mm 16.5mm 19mm) THT ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The Omron G2RL series are a Cubic, Single-pole 10-A Power Relay High Capacity (-E) and 0.8mm Contact Gap (-G) versions Subminiature “sugar cube” relay with universal footprint. Conforms to EN 61810-1. UL recognized/ CSA certified. UL class-F coil insulation model available (UL class-B coil insulation for standard model). Withstands impulse of up to 4,500 V. 400-mW and 360-mW coil power types available Coil Voltage 12VDC Contact Form SPDT (1 Form C) Contact Rating (Current) 16A Switching Voltage 250VAC - Max Coil Type Non Latching Features Insulation - Class F, Sealed - Flux Protection Termination Style PC Pin Operating Temperature -40°C ~ 85°C

Search Keywords: G5LE1EDC12

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Omron Electronics
Part No:
G5LE-1-E-DC12
RoHS:
Yes
HTS:
8536490075
COO:
MY
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
500
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
12 V
Contact Arrangement:
SPDT
Mounting:
Through Hole
Termination Style:
Solder
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-40 to 85 °C
Coil Resistance:
360 Ohm

IN STOCK: 757

Ships today, if you order in

Minimum Order: 10

Factory Lead-Time 4 Weeks

Price (USD)

Qty
Unit Price
10
$2.039
100
$1.679
250
$1.607
500
$1.566
1,000
$1.483
2,500
$1.442
5,000
$1.411
7,500 +
$1.391
Suppliers Standard Package
