G5RL-1-E-HR-DC12 by omron electronics

G5RL-1-E-HR-DC12

Omron Electronics

Power Relay 12VDC 16(NO)/5(NC)A SPDT (29mm 12.7mm 15.7mm) THT ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The OMRON ELECTRONICS part G5RL-1-E-HR-DC12 is a high-quality power relay designed for various applications. It operates at 12VDC and features a single-pole double-throw (SPDT) configuration, offering 16 normally open (NO) and 5 normally closed (NC) terminals for versatile connectivity. With its compact dimensions of 29mm x 12.7mm x 15.7mm, this relay is suitable for through-hole mounting (THT) on a printed circuit board (PCB). It is built to deliver reliable performance and can handle a maximum current of 16A for NO contacts and 5A for NC contacts.

Search Keywords: G5RL1EHRDC12

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Omron Electronics
Part No:
G5RL-1-E-HR-DC12
RoHS:
Yes
HTS:
8536490075
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
12 V
Contact Arrangement:
SPDT
Mounting:
Through Hole
Termination Style:
PC Pin
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-40 to 85 °C
Coil Resistance:
360 Ohm

IN STOCK: 939

Ships today, if you order in

Minimum Order: 5

Factory Lead-Time 26 Weeks

Price (USD)

Qty
Unit Price
5
$4.676
50
$3.801
100
$3.739
300
$3.523
500
$3.327
1,000
$2.822
2,500
$2.750
5,000 +
$2.678
Suppliers Standard Package
Log in for special pricing
Click for Quote
