G5V-1-DC12 by omron electronics
Image is representational - see manufacturer specifications
Omron Electronics Authorized Distributor

G5V-1-DC12

Signal Relay 12VDC 1A SPDT(12.5x7.5x10)mm THT ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The G5V-1-DC12 is an ultra-miniature, highly-sensitive, Low Signal Relay with DC coil for signal circuits. This G5V-1-series PCB mount signal relay has 1CO (SPDT) Au-plated Ag alloy contact. High sensitivity 150mW nominal coil power consumption. Conforms to FCC part 68 requirements for coil to contacts. Wide switching power of 1mA to 1A Fully-sealed construction offering environment resistance -40 to 70°C Operating temperature range Applications Audio, Communications & Networking

Search Keywords: G5V1DC12

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Omron Electronics
Part No:
G5V-1-DC12
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536490050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
500
Relay Construction:
Non-Latching12534
AC Coil Voltage:
N/A
DC Coil Voltage:
12 V
Contact Arrangement:
SPDT12514
Maximum Current Rating:
1 A
Mounting:
Through Hole12526
Operating Temperature:
-40 to 70 °C
Dimension:
12.5 x 10 x 7.5 mm
Termination Style:
PC Pin12536
Coil Current:
12.5 mA
Contact Form:
1 Form C12515

IN STOCK: 9,697

Can Ship immediately

Manufacturer Stock: 35,500   can ship 8/24/26

On Order: 10,000   can ship 12/30/26

Minimum Order Quantity: 25

Factory Lead-Time 32 Weeks can ship 3/22/27

Price (USD)

Qty
Unit Price
25
$2.105
100
$1.793
250
$1.685
500
$1.608
1,000
$1.604
2,500
$1.600
5,000
$1.523
7,500 +
$1.520
Supplier's Standard Package
