G5V-2-H-DC24 by omron electronics

G5V-2-H-DC24

Omron Electronics

Signal Relay 24VDC 2A DPDT( (20.5mm 10.1mm 12mm)) THT ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The OMRON ELECTRONICS G5V-2-H-DC24 is a high-quality signal relay designed with a 24VDC coil voltage and a switching capability of up to 2A. Featuring a double pole double throw (DPDT) configuration, this relay is ideal for applications that require reliable and efficient switching control. With its compact size of 20.5mm x 10.1mm x 12mm, it can easily fit into various circuit boards and panels. This Through-Hole Technology (THT) relay is built with OMRON's renowned craftsmanship, ensuring long-lasting performance and durability.

Search Keywords: G5V2HDC24

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Omron Electronics
Part No:
G5V-2-H-DC24
RoHS:
Yes
HTS:
8536490050
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
500
Relay Construction:
Non-Latching12534
AC Coil Voltage:
N/A
DC Coil Voltage:
24 V
Contact Arrangement:
DPDT12514
Maximum Current Rating:
2 A
Mounting:
Through Hole12526
Operating Temperature:
-25 to 70 °C
Dimension:
20.5 x 10.1 x 11.5 mm
Termination Style:
PC Pin12536
Coil Current:
15 mA
Contact Form:
2 Form C12515

IN STOCK: 259

Ships today, if you order in

On Order: 1,000   can ship 12/3/25

Minimum Order: 10

Factory Lead-Time 26 Weeks

Price (CAD)

Qty
Unit Price
10
$3.981
100
$3.522
250
$3.338
500
$3.185
1,000
$3.048
2,500
$2.863
5,000
$2.725
7,500 +
$2.664
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
