G6A-274P-ST-US-DC24 by omron electronics

G6A-274P-ST-US-DC24

Omron Electronics

Signal Relay 24VDC 2A DPDT(20.2x10.1x8.4)mm THT ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The G6A-274P-ST-US-DC24 is a 2-pole Low Signal Relay with DC coil, G6A series. DPST (2CO) contact configuration. Bifurcated crossbar Ag (Au-alloy) contact, PCB terminals. Stand-off 0.64mm classification. Resistant to electromagnetic interference, enables high-density mounting. Impulse withstand voltage of 1500V meets FCC requirements. Gold-clad twin-contacts provide short contact bounce in addition to its high contact reliability. A variety of products that cover a wide range of use. Single-side stable relay Fully sealed enclosure Operating Temperature -40°C ~ 70°C Applications Industrial, Power Management, Automation & Process Control, Medical, Security, Test & Measurement, Communications & Networking

Search Keywords: G6A274PSTUSDC24

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Omron Electronics
Part No:
G6A-274P-ST-US-DC24
RoHS:
Yes
HTS:
8536410020
COO:
JP
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
500
Relay Construction:
Non-Latching12534
AC Coil Voltage:
N/A
DC Coil Voltage:
24 V
Contact Arrangement:
DPDT12514
Maximum Current Rating:
2 A
Mounting:
Through Hole12526
Operating Temperature:
-40 to 70 °C
Dimension:
20.2 x 10.1 x 8.4 mm
Termination Style:
PC Pin12536
Coil Current:
8.3 mA
Contact Form:
2 Form C12515

IN STOCK: 0

On Order: 5,000   can ship 12/4/25
On Order: 3,827   can ship 12/22/25

Minimum Order: 5

Factory Lead-Time 13 Weeks

Price (CAD)

Qty
Unit Price
5
$8.284
50
$4.961
100
$4.915
250
$4.885
500
$4.854
1,000
$4.839
2,500
$4.808
5,000 +
$4.793
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
