G6AK-234P-ST-US-DC24 by omron electronics

G6AK-234P-ST-US-DC24

Omron Electronics

Signal Relay 24VDC 2A DPDT(20.2x10.1x8.4)mm THT ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The OMRON G6AK-234P-ST-US-DC24 is a high-quality signal relay designed to reliably switch electrical signals in various applications. This relay operates on a 24VDC power supply and provides a double-pole double-throw (DPDT) configuration, allowing for versatile signal routing. With its compact dimensions of 20.2mm x 10.1mm x 8.4mm, this through-hole technology (THT) relay can be easily integrated into PCB designs. Offering a maximum current rating of 2A, the G6AK-234P-ST-US-DC24 ensures efficient signal switching and dependable performance.

Search Keywords: G6AK234PSTUSDC24

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Omron Electronics
Part No:
G6AK-234P-ST-US-DC24
RoHS:
Yes
HTS:
8536410020
COO:
JP
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
500
Relay Construction:
Latching Double Coil
AC Coil Voltage:
N/A
DC Coil Voltage:
24 V
Contact Arrangement:
DPDT
Maximum Current Rating:
2 A
Mounting:
Through Hole
Operating Temperature:
-40 to 70 °C
Dimension:
20.2 x 10.1 x 8.4 mm
Termination Style:
PC Pin
Coil Current:
7.5 mA
Contact Form:
2 Form C

IN STOCK: 472

Can Ship immediately

Minimum Order: 5

Factory Lead-Time 26 Weeks

Price (CAD)

Qty
Unit Price
5
$11.715
25
$9.914
50
$9.806
100
$9.098
250
$8.728
500
$8.682
1,000
$8.636
2,500 +
$8.589
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
