G7L-1A-BUB-J-CB-DC12 by omron electronics
Image is representational - see mfr. specs

G7L-1A-BUB-J-CB-DC12

Omron Electronics

A high-capacity, SPST-NO general-purpose power relay with a 12VDC coil, 30A contact rating, and screw terminals for upper bracket mounting. ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The G7L-1A-BUB-J-CB-DC12 is a high-capacity, general-purpose power relay designed for switching significant loads, particularly those with high inrush currents. This model operates on a 12VDC coil with a power consumption of approximately 1.90W and features SPST-NO contacts rated for a resistive load of 30A at 220VAC. Key features include screw terminals, an upper bracket mount for secure installation, a built-in test button for diagnostics, and UL Class B insulation. The relay offers robust electrical performance with a dielectric strength of 4,000 VAC between the coil and contacts and an impulse withstand voltage of 10,000V. Its durable and safe design makes it ideal for applications like fluid pump controls, HVAC systems, and industrial motor switching.

Search Keywords: G7L1ABUBJCBDC12

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Omron Electronics
Part No:
G7L-1A-BUB-J-CB-DC12
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536490075
COO:
ID
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
20
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
12 V
Contact Arrangement:
SPST-NO
Maximum Current Rating:
30 A
Mounting:
Bracket Mount
Termination Style:
Screw Terminal
Push to Test Button:
Yes
Led Indicator:
No
Operating Temperature:
-25 to 60 °C

IN STOCK: 0

On Order: 100   can ship 7/15/26

Minimum Order Quantity: 20

Multiple: 20

Factory Lead-Time 26 Weeks

Price (USD)

Qty
Unit Price
20
$15.33
40
$14.65
60
$14.22
100
$14.02
260
$13.44
500
$13.08
1,000 +
$12.92
Suppliers Standard Package
