G7L-1A-TUB-CB-AC100/120 by omron electronics

G7L-1A-TUB-CB-AC100/120

Omron Electronics

Power relay ideally suited for high inrush fluid pump control ...

Datasheet
RoHS Compliant
Tray Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The G7L-1A-TUB-CB-AC100/120 is a Power Relay with AC coil. This G7L-series relay has 1NO (SPST) Ag alloy contact with test button. High-capacity, High-dielectric-strength relay compatible with momentary voltage drops. 0.25 inch quick-connect terminals and upper bracket mounting. UL Class B construction standard. Safety design with contact gap of 3mm. Wide-range AC-activated coil Miniature size for maximum switching power, particularly for inductive loads Flame-resistant materials (UL94V-0 qualifying) used for all insulation material No contact chattering for momentary voltage drops up to 50% of rated voltage -25 to 60°C Operating temperature range Applications Power Management, HVAC, Lighting, Motor Drive & Control

Search Keywords: G7L1ATUBCBAC100120

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Omron Electronics
Part No:
G7L-1A-TUB-CB-AC100/120
RoHS:
Yes
HTS:
8536490075
COO:
ID
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
20
Package Type:
Tray
Relay Construction:
Non-Latching
AC Coil Voltage:
100,120 V
DC Coil Voltage:
N/A
Contact Arrangement:
SPST-NO
Maximum Current Rating:
30 A
Mounting:
Bracket Mount
Termination Style:
0.25Quick Connect
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-20 to 60 °C

IN STOCK: 100

Can Ship immediately

On Order: 200   can ship 12/3/25
On Order: 200   can ship 12/29/25

Minimum Order: 20

Multiple: 20

Factory Lead-Time 4 Weeks
