XF2M-1815-1A by omron electronics
Image is representational - see mfr. specs

XF2M-1815-1A

Omron Electronics

Conn FPC Connector SKT 18 POS 0.5mm Solder RA SMD Reel ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The OMRON ELECTRONICS XF2M-1815-1A is a surface-mount FPC connector with 18 positions and a 0.5mm pitch. This connector features solder tail terminations for easy assembly and is supplied on a reel for efficient production processes. Perfect for applications requiring a reliable and compact connection solution.

Search Keywords: XF2M18151A

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Omron Electronics
Part No:
XF2M-1815-1A
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1500
Type:
FPC Connector
Number of Contacts:
18
Pitch:
0.5 mm
Mounting:
Surface Mount
Termination Method:
Solder
Maximum Voltage Rating:
50,50 VDC|VAC
Maximum Current Rating:
0.5 A
Dimension:
13.1mm x 6.2mm x 2.1 mm
Operating Temperature:
-30 to 85 °C

IN STOCK: 4,535

Can Ship immediately

On Order: 7,500   can ship 6/24/26

Minimum Order Quantity: 25

Factory Lead-Time 26 Weeks

Price (USD)

Qty
Unit Price
25
$1.183
250
$1.086
500
$1.060
1,500
$1.004
3,000
$0.997
6,000
$0.992
7,500
$0.987
10,500 +
$0.982
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments
