XF2M-2415-1A by omron electronics

XF2M-2415-1A

Omron Electronics

24 Position FPC Connector Contacts, Top and Bottom 0.020" (0.50mm) Surface Mount, Right Angle ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

0.5mm Pitch Rotary Backlock Low Profile Connectors - XF2M Series 0.5mm pitch FPC connectors with a 2mm on board profile and double-sided contacts. These 0.5mm pitch connectors have a rotary backlock mechanism which aids FPC mounting and provides improved contact reliability, easy operation during assembly and secure mounting in tight spaces. These low profile 0.5mm pitch FPC connectors have LCP resin (UL94V-0) housings and sliders. Suitable applications for these low profile 0.5mm FPC connectors include small mobile devices such as digital cameras, mobile phones, digital audio and video players, DVD players and digital video cameras. Rotary backlock mechanism to ensure secure connection Low 2mm on-board profile Side entry SMT terminals 0.3mm applicable FPC thickness Single row double sided contacts Halogen free

Search Keywords: XF2M24151A

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Omron Electronics
Part No:
XF2M-2415-1A
RoHS:
Yes
HTS:
8536694040
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1500
Type:
FPC Connector
Number of Contacts:
24
Pitch:
0.5 mm
Mounting:
Surface Mount
Termination Method:
Solder
Maximum Voltage Rating:
50,50 VDC|VAC
Maximum Current Rating:
0.5 A
Dimension:
16.1mm x 6.2mm x 2.1 mm
Operating Temperature:
-30 to 85 °C

IN STOCK: 8,451

Ships today, if you order in

Minimum Order: 25

Factory Lead-Time 26 Weeks

Price (USD)

Qty
Unit Price
25
$1.265
250
$0.912
500
$0.902
1,500
$0.898
3,000
$0.893
6,000
$0.889
7,500
$0.885
10,500 +
$0.880
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
