ESD9R3.3ST5G by onsemi
Image is representational - see manufacturer specifications
onsemi Authorized Reseller

ESD9R3.3ST5G

The ESD9R3.3ST5G is an ultra-low capacitance ESD protection diode designed to protect sensitive electronics from electrostatic discharge events. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The ESD9R3.3ST5G is an ultra-low capacitance ESD protection diode created to safeguard ASSPs and ASICs in ultra-low current applications. It operates with a reverse standoff voltage of 3.3 V and features an extremely low leakage current of under 1.0 nA from 0°C to 50°C. Key characteristics include a typical capacitance of 0.5 pF, a minimum breakdown voltage of 4.8 V, and a maximum clamping voltage of 7.8 V at a 1 A peak pulse current. Due to its low capacitance, fast response time, and small SOD-923 package, this device is ideal for protecting high-speed data lines and space-constrained designs like human body sensors.

Search Keywords: ESD9R33ST5G

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
onsemi
Part No:
ESD9R3.3ST5G
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8541100050
COO:
KR
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
8000

IN STOCK: 41,091

Ships today, if you order in

On Order: 40,000   can ship 2/2/28
On Order: 40,000   can ship 2/9/28

Minimum Order Quantity: 1000

Factory Lead-Time 69 Weeks

Price (USD)

Qty
Unit Price
1,000
$0.2336
2,500
$0.2305
5,000
$0.2187
8,000
$0.2159
16,000
$0.2105
32,000
$0.2081
56,000 +
$0.2074
Supplier's Standard Package
Log in for special pricing
