FAN3100TSX by onsemi
Image is representational - see manufacturer specifications
onsemi Authorized Reseller

FAN3100TSX

The FAN3100TSX is a single-channel, 2 A, high-speed, low-side gate driver with TTL input thresholds designed to drive N-channel MOSFETs. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The FAN3100TSX is a single 2 A gate driver designed to drive an N-channel enhancement-mode MOSFET in low-side switching applications. It features TTL-compatible inputs and operates over a wide supply range of 4.5 V to 18 V. The driver provides a high peak sink/source current of 3 A (at VDD = 12 V) to enable fast MOSFET switching, with typical rise and fall times of 13 ns and 9 ns respectively into a 1 nF load. The device incorporates MillerDriveâ„¢ architecture to minimize switching losses and includes an under-voltage lockout (UVLO) function for reliable startup. Packaged in a 5-pin SOT23, it is well-suited for high-frequency designs such as switch-mode power supplies, DC-to-DC converters, and synchronous rectifier circuits.

Search Keywords: FAN3100TSX

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
onsemi
Part No:
FAN3100TSX
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8542390070
COO:
US
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
3000

IN STOCK: 25,286

Ships today, if you order in

Minimum Order Quantity: 50

Factory Lead-Time 14 Weeks

Price (USD)

Qty
Unit Price
50
$0.5880
500
$0.4595
1,000
$0.4504
3,000
$0.4417
6,000
$0.4312
9,000
$0.4301
12,000
$0.4290
27,000 +
$0.4280
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides

Product Changes
