LM317LZG

The LM317LZG is an adjustable 3-terminal positive voltage regulator that supplies over 100 mA for output voltages from 1.2 V to 37 V. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The LM317LZG is an adjustable 3-terminal positive voltage regulator capable of supplying an output current in excess of 100 mA. It provides a nominal reference voltage of 1.25 V and supports an adjustable output voltage range from 1.2 V to 37 V, set by two external resistors. The device features a typical line regulation of 0.01 %/V and load regulation of 0.1% of the output voltage. Integrated protection features include internal current limiting, thermal shutdown, and safe-area compensation, making it robust against overload conditions. The LM317LZG is ideal for various applications, including local on-card regulation and as a precision current regulator.

Search Keywords: LM317LZG

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
onsemi
Part No:
LM317LZG
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8542390070
COO:
CZ
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
2000
Line Regulation:
0.07 %/V
Family:
LM317L
Dimension:
5.2(Max) x 4.19(Max) x 5.33(Max) mm
Function:
LDO
Accuracy:
±4 %
Load Regulation:
0.5 %

IN STOCK: 29,000

Can Ship immediately

Manufacturer Stock: 143,828   can ship 11/16/26

Minimum Order Quantity: 100

Factory Lead-Time 4 Weeks can ship 11/30/26

Price (USD)

Qty
Unit Price
100
$0.2069
2,000
$0.1874
4,000
$0.1824
6,000
$0.1778
8,000
$0.1755
26,000
$0.1712
50,000
$0.1690
100,000 +
$0.1671
