MJE15032G by onsemi
Image is representational - see mfr. specs

MJE15032G

onsemi

The MJE15032G is an NPN silicon power transistor designed for use as a high-frequency driver in audio amplifiers. ...

Datasheet
RoHS Non-Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The MJE15032G is an NPN complementary silicon power transistor specifically designed for high-frequency driver applications. It features a high collector-emitter voltage rating of 250V and supports a continuous collector current of 8.0A, with a peak capability of 16A. Key dynamic characteristics include a high current-gain bandwidth product of at least 30 MHz and a DC current gain of 70 minimum at 1.0A. Housed in a TO-220 package, this transistor's robust performance and 50W power dissipation capability make it an ideal choice for driver stages in audio amplifiers and other power control circuits.

Search Keywords: MJE15032G

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
onsemi
Part No:
MJE15032G
Unit of Measure:
Per Each
RoHS:
No
HTS:
8541290095
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Dimension:
10.28(Max) x 4.82(Max) x 9.28(Max) mm
Family:
MJE15032
Maximum Collector Base Voltage:
250 V

IN STOCK: 8,900

Can Ship immediately

Minimum Order Quantity: 50

Multiple: 50

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
50
$1.053
250
$0.884
500
$0.735
1,000
$0.643
2,500
$0.618
5,000
$0.565
7,500
$0.562
10,000 +
$0.559
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments
