MJL21193G by onsemi
Image is representational - see manufacturer specifications
onsemi Authorized Reseller

MJL21193G

The MJL21193G is a 250V, 16A PNP silicon power transistor designed for high-power audio and linear applications. ...

View Datasheet Ask the Datasheet
RoHS Non-Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The MJL21193G is a silicon power transistor specifically designed for high-power audio output, disk head positioners, and other linear applications. It features a collector-emitter sustaining voltage of 250 Vdc and a minimum DC current gain (hFE) of 25 at a collector current of 8 A. This device also has a typical current-gain bandwidth product of 4 MHz and is characterized for total harmonic distortion. Utilizing Perforated Emitter technology, the MJL21193G provides excellent gain linearity and a high Safe Operating Area (SOA), ensuring robust performance in demanding circuits.

Search Keywords: MJL21193G

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
onsemi
Part No:
MJL21193G
Unit of Measure:
Per Each
RoHS:
No
HTS:
8541290095
COO:
MY
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
25
Dimension:
20.3(Max) x 5.3(Max) x 26.4(Max) mm
Maximum Collector Base Voltage:
400 V
Family:
MJL21193

IN STOCK: 3,075

Ships today, if you order in

Manufacturer Stock: 382   can ship 11/16/26

Minimum Order Quantity: 25

Multiple: 25

Factory Lead-Time 31 Weeks can ship 6/7/27

Price (USD)

Qty
Unit Price
25
$3.86
100
$3.28
250
$2.71
500
$2.64
1,000
$2.63
2,500
$2.62
5,000
$2.61
7,500 +
$2.60
Supplier's Standard Package
