MOCD207M by onsemi
Image is representational - see mfr. specs

MOCD207M

onsemi

The MOCD207M is a dual-channel optocoupler with a phototransistor output, housed in a surface-mountable 8-pin SOIC package for electrical isolation. ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The MOCD207M is a dual-channel optocoupler that contains two gallium arsenide infrared emitting diodes optically coupled to two silicon phototransistor detectors in a single SOIC-8 package. This device features a guaranteed minimum collector-emitter breakdown voltage (BVCEO) of 70 V and a current transfer ratio (CTR) ranging from 40% to 200% at an input forward current of 10 mA. It also provides an input-to-output isolation voltage of 2500 VACRMS for one minute and has a low collector-emitter saturation voltage of 0.4 V maximum. Its dual-channel configuration and surface-mount package make it well-suited for high-density applications such as feedback control circuits, general-purpose switching, and interfacing systems with different potentials.

Search Keywords: MOCD207M

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
onsemi
Part No:
MOCD207M
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8541498000
COO:
TH
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
3000

IN STOCK: 5,125

Can Ship immediately

Minimum Order Quantity: 100

Factory Lead-Time 8 Weeks

Price (USD)

Qty
Unit Price
100
$0.3577
500
$0.3284
1,000
$0.3234
3,000
$0.3113
6,000
$0.3034
9,000
$0.2988
12,000
$0.2944
27,000 +
$0.2899
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
