NDP6060L by onsemi
onsemi Authorized Reseller

NDP6060L

The NDP6060L is an N-Channel logic level enhancement mode power field effect transistor designed for low voltage applications. ...

View Datasheet Ask the Datasheet
RoHS Non-Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The NDP6060L is a logic level N-Channel enhancement mode power field effect transistor produced using a proprietary, high cell density DMOS technology. It is rated for a drain-source voltage of 60V and a continuous drain current of 48A. Key features include an extremely low on-state resistance of 0.025 Ω at VGS = 5V, a low gate threshold voltage under 2.0V for direct operation from logic drivers, and a high maximum junction temperature rating of 175°C. This device is specifically tailored to minimize on-state resistance, provide superior switching performance, and withstand high energy pulses. It is particularly suited for automotive applications, DC/DC converters, PWM motor controls, and other battery-powered circuits where fast switching and low power loss are critical.

Search Keywords: NDP6060L

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
onsemi
Part No:
NDP6060L
Unit of Measure:
Per Each
RoHS:
No
HTS:
8541290095
COO:
KR
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
50

IN STOCK: 4,800

Can Ship immediately

Minimum Order Quantity: 50

Multiple: 50

Factory Lead-Time 23 Weeks

Price (USD)

Qty
Unit Price
50
$2.29
250
$2.12
500
$1.76
1,000
$1.75
2,500
$1.74
5,000
$1.73
7,500
$1.72
10,000 +
$1.71
Supplier's Standard Package
