NSR20F40NXT5G by onsemi
onsemi Authorized Reseller

NSR20F40NXT5G

The NSR20F40NXT5G is a 40V, 2.0A Schottky barrier diode optimized for low forward voltage drop and low leakage current in a Chip Scale Package (CSP). ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The NSR20F40NXT5G is a Schottky barrier diode designed for high efficiency and space-constrained applications. It is rated for a maximum reverse voltage of 40V and a continuous forward current of 2.0A. Key features include a very low forward voltage drop of 550 mV at 2.0A and a low reverse leakage current of 15 µA at 10V. The device can handle a forward surge current up to 28A and has a repetitive peak forward current rating of 4.0A. Its high switching speed and low thermal resistance make it suitable for applications like buck and boost DC-DC converters, reverse voltage protection, and clamping circuits in portable electronics.

Search Keywords: NSR20F40NXT5G

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
onsemi
Part No:
NSR20F40NXT5G
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8541100040
COO:
MY
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
5000

IN STOCK: 3,501

Can Ship immediately

Manufacturer Stock: 60,000   can ship 8/28/26

Minimum Order Quantity: 250

Factory Lead-Time 18 Weeks can ship 12/17/26

Price (USD)

Qty
Unit Price
250
$0.1307
2,500
$0.1199
5,000
$0.1183
10,000
$0.1123
25,000
$0.1108
50,000
$0.1080
100,000
$0.1068
150,000 +
$0.1055
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request
