PN2222ABU by onsemi
Image is representational - see mfr. specs

PN2222ABU

onsemi

The PN2222A is a general-purpose NPN silicon transistor for amplification and switching applications. ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The PN2222ABU is a general-purpose NPN silicon transistor designed for medium-current amplification and switching. It features a maximum collector-emitter voltage of 40 V, a continuous collector current rating of 600 mA, and a total device dissipation of 625 mW. This device provides a minimum current-gain-bandwidth product of 300 MHz and a DC current gain (hFE) between 100 and 300 at a collector current of 150 mA. Due to its balanced specifications, the PN2222ABU is widely used in driver stages, low-power output stages, and various signal processing circuits.

Search Keywords: PN2222ABU

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
onsemi
Part No:
PN2222ABU
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8541210095
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
10000

IN STOCK: 121,402

Ships today, if you order in

Minimum Order Quantity: 500

Factory Lead-Time 25 Weeks

Price (USD)

Qty
Unit Price
500
$0.0707
5,000
$0.0508
10,000
$0.0503
30,000
$0.0484
50,000
$0.0430
100,000
$0.0428
150,000
$0.0427
250,000 +
$0.0426
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments
