ALF1T24 by panasonic electronic components
Image is representational - see manufacturer specifications
Panasonic Electronic Components Authorized Distributor

ALF1T24

The ALF1T24 is a 1 Form A power relay with a 24V DC nominal coil voltage and TMP-style terminals, designed for high-current switching. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The ALF1T24 is a 1 Form A power relay featuring a 24V DC nominal coil voltage and TMP-style terminals. It is engineered to handle demanding loads, with a nominal switching capacity of 20A at 250V AC for resistive loads and specific ratings for compressor and inverter loads. The relay provides robust insulation with a minimum creepage distance of 9.5mm between contact and coil and a surge withstand voltage of 10,000V. Its electrical characteristics include a nominal operating power of 900mW and a coil resistance of 640 Ω. Due to these features, the ALF1T24 is ideal for applications such as air conditioners, refrigerators, and office automation equipment.

Search Keywords: ALF1T24

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
ALF1T24
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410050
COO:
TH
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
50
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
24 V
Contact Arrangement:
SPST-NO
Mounting:
Top Mount
Termination Style:
Quick Connect/PC Pin
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-40 to 60 °C

IN STOCK: 19

Can Ship immediately

On Order: 2,000   can ship 12/16/26

Minimum Order Quantity: 3

Factory Lead-Time 25 Weeks

Price (USD)

Qty
Unit Price
3
$4.10
10
$4.06
25
$4.02
50
$3.18
100
$2.78
250
$2.61
500
$2.54
1,000 +
$2.47
Supplier's Standard Package
Log in for special pricing
