AQG22224 by panasonic electronic components
Image is representational - see mfr. specs

AQG22224

Panasonic Electronic Components

Solid State Relay 28.8V DC-IN 2A 264V AC-OUT 4-Pin Slim ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

AQG22224 is a slim type solid state relay (SSR) designed for AC load control applications. It features a random switching method with a rated control voltage of 24 V DC (19.2 to 28.8 V DC range), a maximum load current of 2 A, and a load voltage range of 75 to 264 Vrms. The relay offers high dielectric strength of 3,000 Vrms between input and output, a maximum thickness of 4.5 mm, and includes a built-in snubber circuit to prevent malfunction due to noise. With input impedance of approximately 1.6 kO and certifications including C-UL (UL508) and VDE (EN60950-1) reinforced insulation, this SSR is suitable for household appliances, healthcare equipment, industrial machinery, and microcomputer boards.

Search Keywords: AQG22224

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
AQG22224
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536490080
COO:
JP
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
20
Output Type:
AC
Maximum Output Voltage:
264 V
Maximum Output Current:
2 A
Output Device:
N/A
Input Type:
DC
Input Voltage:
28.8 V
Mounting:
Through Hole
Circuit Arrangement:
N/A
Dimension:
24.5(Max) x 4.5(Max) x 20.5(Max) mm

IN STOCK: 220

Can Ship immediately

On Order: 300   can ship 7/1/26

Minimum Order Quantity: 20

Multiple: 20

Factory Lead-Time 14 Weeks

Price (USD)

Qty
Unit Price
20
$3.83
60
$3.69
100
$3.55
260
$3.37
500
$3.24
1,000
$3.13
2,500
$3.12
5,000 +
$3.11
Suppliers Standard Package
