AQV258 by panasonic electronic components
Image is representational - see mfr. specs

AQV258

Panasonic Electronic Components

Solid State Relay 50mA 1.5V DC-IN 0.02A 1200V AC/DC-OUT 6-Pin DIP Tube ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The AQV258 is a DIP6-pin PhotoMOS relay featuring reinforced insulation with 1,500 Vrms I/O isolation and AC/DC dual-use capability. It is designed for high-voltage switching applications with a maximum load voltage of 1,500 V peak AC and a continuous load current rating of 20 mA (A connection) or 25 mA (B connection). The device operates over an ambient temperature range of -40°C to +85°C and features low on-resistance characteristics typical of the PhotoMOS family. The reinforced insulation design makes it suitable for demanding applications in measuring instruments, data communication equipment, telephone systems, and automatic meter reading devices where galvanic isolation and high-voltage switching are required.

Search Keywords: AQV258

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
AQV258
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410020
COO:
JP
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Output Type:
AC,DC
Maximum Output Voltage:
1500 V
Maximum Output Current:
0.02 A
Output Device:
MOSFET
Input Type:
DC
Input Voltage:
1.5 V
Mounting:
Through Hole
Circuit Arrangement:
1 Form A
Dimension:
8.8 x 6.4 mm

IN STOCK: 1,133

Ships today, if you order in

Minimum Order Quantity: 50

Multiple: 50

Factory Lead-Time 14 Weeks

Price (USD)

Qty
Unit Price
50
$3.77
100
$3.69
250
$3.64
500
$3.53
1,000
$3.04
2,500
$3.00
5,000
$2.98
7,500 +
$2.97
Suppliers Standard Package
