AQW214AZ by panasonic electronic components
Image is representational - see manufacturer specifications
Panasonic Electronic Components Authorized Distributor

AQW214AZ

Solid State Relay 50mA 1.5V DC-IN 0.13A 320V AC/DC-OUT 8-Pin DIP SMD T/R ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The AQW214AZ is a compact PhotoMOS relay designed for AC/DC dual-use applications with a maximum load voltage of 400V peak AC and 100mA continuous load current in single-channel operation (130mA peak). This 8-pin DIP surface mount terminal device features high sensitivity and high-speed response characteristics, with a low off-state leakage current of maximum 1 µA, making it suitable for controlling low-level analog signals. The relay operates over an ambient temperature range of -40°C to +85°C and can be configured as either two independent 1 Form A channels or a single 2 Form A relay. Typical applications include high-speed inspection machines, telephone equipment, and computer systems where reliable signal switching and isolation are required.

Search Keywords: AQW214AZ

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
AQW214AZ
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8541498000
COO:
JP
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1000
Output Type:
AC,DC
Maximum Output Voltage:
400 V
Maximum Output Current:
0.1 A
Output Device:
MOSFET
Input Type:
DC
Input Voltage:
1.5 V
Mounting:
Surface Mount
Circuit Arrangement:
2 Form A
Dimension:
9.78 x 6.4 mm
  Different packaging options available.  See Alternatives

IN STOCK: 586

Can Ship immediately

Minimum Order Quantity: 10

Factory Lead-Time 34 Weeks

Price (USD)

Qty
Unit Price
10
$7.95
50
$5.41
100
$4.83
250
$4.60
500
$4.43
1,000
$4.40
3,000
$4.39
5,000 +
$4.38
