AV4444 by panasonic electronic components
Image is representational - see mfr. specs

AV4444

Panasonic Electronic Components

Switch Snap Action N.O./N.C. SPDT Simulated Roller Lever PC Pins 0.5A 30VDC 0.29N Thru-Hole ...

Datasheet
RoHS Compliant
Packaging
Accessories
Discontinued
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

AV4444 is a superminiature snap-action switch featuring a simulated roller lever actuator and straight PC board terminal configuration, designed for compact applications requiring reliable switching performance. The switch operates with a maximum operating force of 0.29 N and offers a mechanical life of at least 300,000 operations at 60 cycles per minute. It features silver-plated contacts rated for 0.5 A at 30 V DC, with an initial contact resistance of maximum 200 mO and insulation resistance of at least 100 MO. The device operates over an ambient temperature range of -25°C to +80°C and weighs approximately 0.2 g in its PC board terminal configuration. AV4444 is ideal for compact visual equipment such as cameras and portable VCRs, small-sized audio equipment, and office automation devices where space constraints and reliable switching are critical requirements.

Search Keywords: AV4444

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
AV4444
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536507000
COO:
JP
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
500
Mounting:
PCB Mount
Pole Throw Configuration:
SPDT
Switch Configuration:
N.O./N.C.
Actuator Material/Style:
Simulated Roller Lever
Contact Rating @ Voltage:
0.5@30VDC A
Maximum Movement Differential:
0.7 mm
Operating Force:
0.29 N
Termination Style:
PC Pins
Dimension:
7.5 x 2.5 x 8 mm
Body Orientation:
Straight
IP Rating:
N/A
Life Cycle:
Discontinued
  This product is discontinued, but still in stock

IN STOCK: 20

Can Ship immediately

Buy all 20 in-stock or the regular minimum order quantity of 25

Stock lot only: 20

Minimum Order Quantity: 25

Price (USD)

Qty
Unit Price
1
$2.9186
25
$2.6533
100
$1.8540
250
$1.5337
500
$1.4389
1,000
$1.3936
2,500
$1.3864
5,000
$1.3792
7,500 +
$1.3720
Suppliers Standard Package
