AXK880145WG by panasonic electronic components
Image is representational - see mfr. specs

AXK880145WG

Panasonic Electronic Components

Conn Board to Board PL 80 POS 0.4mm Solder ST SMD T/R ...

Datasheet
RoHS Compliant
Packaging
Accessories
Discontinued
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

AXK880145WG is a narrow pitch board-to-board header connector designed for reliable interconnection in compact electronic assemblies. This connector features a 0.4 mm pitch with 80 pins and is available in multiple mated heights including 2.0 mm, 2.5 mm, and 3.0 mm configurations. It utilizes Panasonic's "Tough Contact" construction for high contact reliability and strong resistance to adverse environments, along with impact dispersion keys inside the body to disperse shocks when dropped. The connector is RoHS compliant and designed without soldering terminals. Common applications include board-to-board and board-to-FPC connections in space-constrained electronic devices where high reliability and shock resistance are required.

Search Keywords: AXK880145WG

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
AXK880145WG
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
JP
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
3000
Type:
Board to Board
Body Orientation:
Straight
Gender:
HDR
Mounting:
Surface Mount
Pitch:
0.4 mm
Number of Contacts:
80
Maximum Voltage Rating:
60,60 VDC|VAC
Maximum Current Rating:
5 A
Termination Method:
Solder
Operating Temperature:
-55 to 85 °C
Life Cycle:
Discontinued
  This product is discontinued, but still in stock

IN STOCK: 4,873

Can Ship immediately

Minimum Order Quantity: 10

Price (USD)

Qty
Unit Price
10
$1.75
100
$1.57
250
$1.52
500
$1.50
1,000
$1.46
3,000
$1.44
6,000
$1.42
9,000 +
$1.40
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request

Tools/3D Models

Product Guides

Accessories

AXK780147G

Conn Board to Board RCP 80 POS 0.4mm Solder ST SMD T/R
