CB1A-12V by panasonic electronic components
Image is representational - see mfr. specs

CB1A-12V

Panasonic Electronic Components

Relays 12VDC 103Ohm 40A SPST-NO(26mm 22mm 36mm) Plug-In Automotive Relay Automotive ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

CB1A-12V is a Mini-ISO automotive relay designed for automotive control applications requiring compact, high-capacity switching. This relay features a 1 Form A contact arrangement with a 12V DC rated coil voltage, plug-in mounting classification, and flux-tight protective construction for sealed operation. The relay operates with a rated operating current of 117 mA, coil resistance of 103 O, and rated operating power of 1.4 W, with a usable voltage range of 10 to 16V DC. It provides a rated switching capacity of 40 A at 14V DC (resistive), maximum contact resistance of 15 mO, and silver alloy contacts for reliable performance. The CB1A-12V is commonly used in automotive cell motors, air conditioners, ABS systems, and EPS applications, offering compact design with high switching capacity and heat-resistant construction options for demanding automotive environments.

Search Keywords: CB1A12V

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
CB1A-12V
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410050
COO:
JP
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Contact Form:
SPST-NO (1 Form A)
Relay Construction:
Non-Latching
Max Contact Current:
40A
Coil Voltage:
12 VDC
Coil Current:
117 mA
Coil Resistance:
103 Ohm
Contact Material:
Silver(Cadmium Free)
Must Operate Voltage:
7 VDC
Must Release Voltage:
4.2 VDC
Operate Time:
15 ms
Seal:
Sealed
Mounting:
Connector
Termination Style:
0.25 Quick Connect
Dimension:
26 x 22 x 36 mm
Operating Temperature:
-40 to 85 °C
Packaging:
Carton

IN STOCK: 860

Ships today, if you order in

Minimum Order Quantity: 50

Multiple: 50

Factory Lead-Time 24 Weeks

Price (USD)

Qty
Unit Price
50
$3.12
100
$3.04
250
$2.99
500
$2.82
1,000
$2.81
2,500
$2.80
5,000
$2.79
7,500 +
$2.78
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
