CB1AH-12V by panasonic electronic components
Image is representational - see mfr. specs

CB1AH-12V

Panasonic Electronic Components

Power Relay 12VDC 40A SPST-NO(26x22x25)mm Socket Automotive ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

CB1AH-12V is a Mini-ISO automotive relay designed for high contact capacity applications in automotive and industrial environments. It features a 1 Form A contact arrangement with sealed protective construction and a rated coil voltage of 12V DC. The relay operates with a coil resistance of 103O, rated operating current of 117mA, and rated operating power of 1.4W, with a usable voltage range of 10 to 16V DC. Key contact specifications include a rated switching capacity of 20A at 28V DC (resistive), maximum carrying current of 20A at 85°C continuous, and contact resistance of max. 15mO. This relay is commonly used in automobiles for cell motors, air conditioners, ABS, and EPS systems, as well as in construction and agricultural equipment.

Search Keywords: CB1AH12V

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
CB1AH-12V
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410050
COO:
JP
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Contact Form:
SPST-NO (1 Form A)
Relay Construction:
Non-Latching
Max Contact Current:
40A
Coil Voltage:
12 VDC
Coil Current:
150 mA
Coil Resistance:
80 Ohm
Contact Material:
Silver(Cadmium Free)
Must Operate Voltage:
7 VDC
Must Release Voltage:
4.2 VDC
Operate Time:
15 ms
Seal:
Sealed
Mounting:
Connector
Termination Style:
0.25 Quick Connect
Dimension:
26 x 22 x 36 mm
Operating Temperature:
-40 to 85 °C
Packaging:
Carton

IN STOCK: 2,810

Ships today, if you order in

Minimum Order Quantity: 50

Multiple: 50

Factory Lead-Time 24 Weeks

Price (USD)

Qty
Unit Price
50
$4.21
100
$4.16
250
$4.11
500
$4.07
1,000
$4.03
2,500
$3.99
5,000 +
$3.97
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
