CB1A-M-12V

Relays 12VDC 103Ohm 40A SPST-NO(30mm 22mm 52mm) Bracket Automotive Relay Automotive ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The PANASONIC EW/AROMAT CB1A-M-12V relay is an essential component for automotive applications that require reliable and efficient power distribution. This 12VDC relay is designed to handle high-current loads of up to 40A, making it ideal for automotive lighting, power windows, starter systems, and other vital functions.Featuring a single-pole, single-throw normally open configuration, this relay provides reliable switching capabilities while maintaining a compact design. With a coil resistance of 103 Ohm, it ensures smooth and consistent operation, even in harsh automotive environments.The relay is housed within a durable and compact plastic casing, measuring 30mm x 22mm x 52mm, making it suitable for various automotive installations. Additionally, it comes with a bracket for easy mounting, ensuring a secure and stable connection.Whether you're upgrading your automotive electrical system or replacing a faulty relay, the PANASONIC EW/AROMAT CB1A-M-12V relay is the perfect choice. With its high-performance capabilities, robust construction, and versatile design, this relay guarantees long-lasting performance and reliable operation in automotive applications.

Search Keywords: CB1AM12V

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
CB1A-M-12V
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410050
COO:
JP
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
200
Contact Form:
SPST-NO (1 Form A)
Relay Construction:
Non-Latching
Max Contact Current:
40A
Coil Voltage:
12 VDC
Coil Current:
117 mA
Coil Resistance:
103 Ohm
Contact Material:
Silver(Cadmium Free)
Must Operate Voltage:
7 VDC
Must Release Voltage:
4.2 VDC
Operate Time:
15 ms
Seal:
Sealed
Mounting:
Bracket Mount
Termination Style:
0.25 Quick Connect
Dimension:
30 x 22 x 52 mm
Operating Temperature:
-40 to 85 °C
Packaging:
Carton

IN STOCK: 780

Ships today, if you order in

On Order: 2,000   can ship 7/9/27

Minimum Order Quantity: 5

Factory Lead-Time 38 Weeks
