Image is representational - see manufacturer specifications
Panasonic Electronic Components Authorized Distributor

CB1-M-24V

Power Relay 24VDC 20(NO)/10(NC)A SPDT(22x26x52)mm Bracket Automotive ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The PANASONIC EW/AROMAT CB1-M-24V is a powerful and reliable power relay designed for automotive applications. With a voltage rating of 24VDC, this relay is capable of handling high electrical loads up to 20A normally open (NO) and 10A normally closed (NC). Featuring a Single Pole Double Throw (SPDT) configuration, this compact relay has dimensions of 22x26x52mm, making it suitable for various automotive installations. It comes with a convenient bracket for secure mounting and easy integration into your automotive systems.Built with top-notch quality, the PANASONIC EW/AROMAT CB1-M-24V power relay ensures excellent performance and long-lasting durability in demanding automotive environments. Whether it's for vehicle lighting, power windows, door locks, or other automotive applications, this power relay is a reliable choice.

Search Keywords: CB1M24V

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
CB1-M-24V
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410050
COO:
JP
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
200
Contact Form:
SPDT (1 Form C)
Relay Construction:
Non-Latching
Max Contact Current:
20A (NO) / 10A (NC)
Coil Voltage:
24 VDC
Coil Current:
75 mA
Coil Resistance:
320 Ohm
Contact Material:
Silver(Cadmium Free)
Must Operate Voltage:
14 VDC
Must Release Voltage:
8.4 VDC
Operate Time:
15 ms
Seal:
Sealed
Mounting:
Bracket Mount
Termination Style:
0.25 Quick Connect
Dimension:
30 x 22 x 52 mm
Operating Temperature:
-40 to 85 °C
Packaging:
Carton

IN STOCK: 608

Can Ship immediately

On Order: 1,000   can ship 12/23/26

Minimum Order Quantity: 5

Factory Lead-Time 24 Weeks

Price (USD)

Qty
Unit Price
5
$6.20
50
$5.02
200
$4.64
400
$4.62
600
$4.47
1,000
$4.33
2,600
$4.31
5,000 +
$4.30
