HE1AN-S-DC12V by panasonic electronic components
Image is representational - see mfr. specs

HE1AN-S-DC12V

Panasonic Electronic Components

Power Relay 12VDC 30A SPST-NO(51x34x52.8)mm ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The HE1AN-S-DC12V is a 1 Form A single-side stable power relay manufactured by Panasonic with a nominal coil voltage of 12V DC and screw terminal connections. This relay features a contact capacity of 30A and demonstrates excellent resistance to contact welding through its pre-tension and kick-off mechanism, passing TV-15 rating standards. The relay offers high reliability with an electrical life of 2×105 operations at 20 cycles per minute and mechanical life of 107 operations at 180 cycles per minute for DC type operation. It provides surge voltage protection exceeding 10,000V between contacts and coil, and is certified to major safety standards including UL, CSA, VDE, and TÜV. The HE1AN-S-DC12V is ideal for office equipment applications such as copiers and air conditioning units where reliable switching and long operational life are essential.

Search Keywords: HE1ANSDC12V

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
HE1AN-S-DC12V
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410050
COO:
JP
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
10
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
12 V
Contact Arrangement:
SPST-NO
Mounting:
N/A
Termination Style:
Screw Terminal
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-50 to 55 °C

IN STOCK: 30

Ships today, if you order in

Factory Lead-Time 12 Weeks

Price (USD)

Qty
Unit Price
1
$39.00
5
$36.65
10
$35.65
30
$34.04
50
$33.30
100
$32.29
250 +
$30.96
