HE2AN-Q-AC120V by panasonic electronic components

HE2AN-Q-AC120V

Panasonic Electronic Components

Power Relay 120VAC 25A DPST-NO(60x33x46.2)mm Flange ...

Datasheet
RoHS Compliant
BOX Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The Panasonic EW/Aromat HE2AN-Q-AC120V is a power relay designed for a 120VAC input voltage. With a 25A current rating and a DPST-NO contact configuration, it is suitable for high-power applications. The relay is compact, measuring only 60x33x46.2mm, and features a flange for easy installation. It is a reliable and durable component that ensures safe and efficient electrical switching.

Search Keywords: HE2ANQAC120V

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
HE2AN-Q-AC120V
RoHS:
Yes
HTS:
8536410050
COO:
JP
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
20
Package Type:
BOX
Relay Construction:
Non-Latching
AC Coil Voltage:
120 V
DC Coil Voltage:
N/A
Contact Arrangement:
DPST-NO
Mounting:
Flange Mount
Termination Style:
0.25Quick Connect
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-50 to 55 °C

IN STOCK: 434

Ships today, if you order in

On Order: 255   can ship 2/2/26
On Order: 1,500   can ship 3/25/26

Factory Lead-Time 40 Weeks

Price (CAD)

Qty
Unit Price
1
$59.368
5
$55.540
20
$52.232
40
$50.594
100
$48.404
260
$46.123
500 +
$44.989
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
