HY1-12V by panasonic electronic components

HY1-12V

Panasonic Electronic Components

Signal Relay 12VDC 1A SPDT(12x7.4x10.1)mm THT ...

Datasheet
RoHS Compliant
BOX Packaging
Accessories
Discontinued & Replaced
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The PANASONIC EW/AROMAT HY1-12V is a reliable and versatile signal relay designed for a variety of applications. With a coil voltage of 12VDC and a contact rating of 1A, this SPDT (Single-Pole Double-Throw) relay offers great performance and functionality. Its compact size (12x7.4x10.1mm) makes it ideal for space-constrained designs. Featuring Through-Hole Technology (THT), this relay can be easily soldered onto a PCB for secure and stable connections. Whether used in telecommunications, automotive, or industrial equipment, this PANASONIC relay guarantees excellent performance and durability.

Search Keywords: HY112V

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
HY1-12V
RoHS:
Yes
HTS:
8536410020
COO:
JP
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Package Type:
BOX
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
12 V
Contact Arrangement:
SPDT
Maximum Current Rating:
1 A
Mounting:
Through Hole
Operating Temperature:
-40 to 70 °C
Dimension:
12 x 7.4 x 10.1 mm
Termination Style:
PC Pin
Coil Current:
12.5 mA
Contact Form:
1 Form C
Life Cycle:
Discontinued & Replaced
  This product is discontinued, but still in stock

IN STOCK: 727

Ships today, if you order in

Minimum Order: 50

Multiple: 50

Price (CAD)

Qty
Unit Price
50
$7.188
100
$6.788
250
$6.641
500
$6.238
1,000
$6.174
2,500
$6.110
5,000
$6.079
7,500 +
$6.049
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
RECOMMENDED REPLACEMENT
DS1E-S-12V
DS1E-S-12V
VIEW PRODUCT
