JS1-12V-F by panasonic electronic components

JS1-12V-F

Panasonic Electronic Components

General purpose relay - Electromechanical relay – Miniature PCB type power relay - Miniature size with universal terminal footprint - High contact capacity - Sealed construction for automatic cleaning - SPDT (1 Form C) – Silver Tin Oxide – 12 mm (H) x 16 ...

Datasheet
RoHS Compliant
BOX Packaging
Accessories
Discontinued
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The PANASONIC EW/AROMAT JS1-12V-F is a miniature PCB, general purpose SPDT plastic sealed relay with universal terminal footprint, high contact capacity and through hole mounting. It has a voltage rating of 12 VDC and a current rating of 10 A. This relay can be used for home appliances (air conditioner, heater), office machines (PPC, facsimile), and vending machines.

Search Keywords: JS112VF

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
JS1-12V-F
RoHS:
Yes
HTS:
8536490050
COO:
TH
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Package Type:
BOX
Relay Construction:
Non-Latching10725
AC Coil Voltage:
N/A
DC Coil Voltage:
12 V
Contact Arrangement:
SPDT10703
Maximum Current Rating:
10
Mounting:
Through Hole10716
Termination Style:
PC Pin10727
Push to Test Button:
No10724
Led Indicator:
No10708
Operating Temperature:
-40 to 70 °C
Coil Resistance:
400 Ohm
Life Cycle:
Discontinued
  This product is discontinued, but still in stock

IN STOCK: 46,711

Can Ship immediately

Minimum Order: 100

Multiple: 100

Price (USD)

Qty
Unit Price
100
$2.153
200
$1.617
500
$1.288
1,000
$1.030
2,500
$0.989
5,000
$0.968
10,000 +
$0.917
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
