JTN1AS-PA-F-DC24V by panasonic electronic components

JTN1AS-PA-F-DC24V

Panasonic Electronic Components

Power Relay 24VDC 30A SPST-NO(31.9x26.9x20.2)mm THT ...

Datasheet
RoHS Compliant
BOX Packaging
Accessories
Discontinued & Replaced
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The PANASONIC EW/AROMAT part JTN1AS-PA-F-DC24V is a high-quality power relay designed for various applications. With a compact size measuring 31.9x26.9x20.2mm, this relay is perfect for space-constrained installations. It operates on a 24VDC power supply and features a Single Pole Single Throw Normally Open configuration, capable of handling up to 30A of current. Its Through-Hole Technology (THT) ensures easy and secure mounting on circuit boards. Trust this reliable and durable power relay from PANASONIC EW/AROMAT for your electrical systems.

Search Keywords: JTN1ASPAFDC24V

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
JTN1AS-PA-F-DC24V
RoHS:
Yes
HTS:
8536410050
COO:
TH
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Package Type:
BOX
Relay Construction:
Non-Latching10725
AC Coil Voltage:
N/A
DC Coil Voltage:
24 V
Contact Arrangement:
SPST-NO10703
Mounting:
Through Hole10716
Termination Style:
PC Pin10727
Push to Test Button:
No10724
Led Indicator:
No10708
Operating Temperature:
-55 to 85 °C
Life Cycle:
Discontinued & Replaced
  This product is not in stock and cannot be back-ordered
Please Note: Tariffs may apply for U.S. shipments
Older Equivalent
JTN1AG-PA-F-DC24V
JTN1AG-PA-F-DC24V
VIEW PRODUCT
