Power Relay 12VDC 10A SPST-NO(28.6x12.8x20)mm THT ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

JW1AFSN-DC12V-F is a high capacity power relay designed for switching applications requiring up to 10A contact capacity. This sealed relay features a 1 Form A (SPST-NO) contact arrangement with AgSnO2 contact material and operates with a 12V DC rated coil voltage. The miniature/slim design measures 12.8 mm (width) × 28.6 mm (length) × 20 mm (height), making it suitable for space-constrained PCB mounting. With switching capabilities of 10A at 250V AC and 10A at 30V DC resistive loads, and a minimum electrical life of 10^5 operations, this relay is ideal for home appliances, office machines, and industrial equipment applications.
