JW2SN-DC48V by panasonic electronic components

JW2SN-DC48V

Panasonic Electronic Components

Power Relay 48VDC 5A DPDT(28.6mm 12.8mm 20mm) THT ...

Datasheet
RoHS Non-Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The PANASONIC EW/AROMAT part JW2SN-DC48V is a reliable and versatile power relay designed for 48VDC applications. This double-pole double-throw (DPDT) relay is capable of handling up to 5A of current. With compact dimensions of 28.6mm x 12.8mm x 20mm, this through-hole technology (THT) relay is easy to install and suitable for a variety of electronic devices and systems. Trust in the quality and performance of PANASONIC EW/AROMAT for your switching needs.

Search Keywords: JW2SNDC48V

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
JW2SN-DC48V
RoHS:
No
HTS:
8536490050
COO:
TH
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
100
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
48 V
Contact Arrangement:
DPDT
Maximum Current Rating:
5 A
Mounting:
Through Hole
Termination Style:
PC Pin
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-40 to 60 °C
Coil Resistance:
4.4 KOhm
  This product is NOT RoHS Compliant.  See Alternatives

IN STOCK: 1,697

Can Ship immediately

Minimum Order: 10

Factory Lead-Time 24 Weeks

Price (CAD)

Qty
Unit Price
10
$4.013
50
$3.293
300
$3.109
500
$3.094
1,000
$3.077
2,500
$3.063
5,000
$3.048
7,500 +
$3.031
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments

Tools/3D Models

Product Guides

Product Changes
