SP-MA by panasonic electronic components
Image is representational - see manufacturer specifications
Panasonic Electronic Components Authorized Distributor

SP-MA

Relay Accessories Base Plate for Power Relay ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
Certificate of Compliance

DESCRIPTION

SP-MA is a mounting board designed for Panasonic SP polarized power relays, providing flexible installation options for both 2 Form C and 4 Form C relay types. The board features a compact design with dimensions of 56.2 mm × 25 mm × 23.2 mm and includes two M3 mounting holes with a pitch of 18.4 mm, allowing direct chassis mounting or compatibility with standard 35 mm DIN rails (DIN46277). This accessory simplifies relay integration into control systems and industrial equipment by providing a standardized mounting interface. The SP-MA board is commonly used in automation controls, railway signal equipment, and industrial power device applications where reliable relay mounting and accessibility are essential.

Search Keywords: SPMA

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
SP-MA
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536694040
COO:
JP
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
10

IN STOCK: 755

Can Ship immediately

Minimum Order Quantity: 10

Multiple: 10

Factory Lead-Time 26 Weeks

Price (USD)

Qty
Unit Price
10
$9.61
30
$8.89
100
$8.40
250
$7.99
500
$7.71
1,000
$7.45
2,500 +
$7.43
Supplier's Standard Package
Log in for special pricing Click for Quote Price Match Request
