ST1-DC12V-F by panasonic electronic components

ST1-DC12V-F

Panasonic Electronic Components

Power Relay 12VDC 8A SPST-NO/SPST-NC(31x14x11.3)mm THT ...

Datasheet
RoHS Compliant
BOX Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The PANASONIC EW/AROMAT ST1-DC12V-F is a high-quality power relay designed for various electrical applications. It operates at 12VDC and has a contact rating of 8A. This relay features a single pole, single throw normally open and normally closed configuration, making it versatile for both SPST-NO and SPST-NC applications. With its compact dimensions of 31x14x11.3mm, this through-hole technology (THT) relay is easy to integrate into any electronic circuit or system. It offers reliable performance, ensuring smooth power switching and efficient signal control. Whether used in automotive, industrial, or other electronic equipment, the PANASONIC EW/AROMAT ST1-DC12V-F power relay is a dependable and space-saving solution for your 12VDC power control needs.

Search Keywords: ST1DC12VF

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
ST1-DC12V-F
RoHS:
Yes
HTS:
8536410020
COO:
JP
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Package Type:
BOX
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
12 V
Contact Arrangement:
SPST-NO,SPST-NC
Mounting:
Through Hole
Termination Style:
PC Pin
Push to Test Button:
No
Led Indicator:
No
Operating Temperature:
-40 to 60 °C
Coil Resistance:
600 Ohm

IN STOCK: 341

Can Ship immediately

Minimum Order: 5

Factory Lead-Time 16 Weeks

Price (CAD)

Qty
Unit Price
5
$25.879
25
$16.630
50
$15.420
100
$14.547
250
$13.215
500
$12.679
1,000 +
$12.450
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
