TQ2SA-12V-Z by panasonic electronic components
Image is representational - see mfr. specs

TQ2SA-12V-Z

Panasonic Electronic Components

Signal Relay 12VDC 2A DPDT(14x11.5x5.6)mm SMD ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The PANASONIC EW/AROMAT TQ2SA-12V-Z is a compact and highly reliable signal relay designed for various industrial and electronic applications. With a rating of 12VDC and 2A, this double-pole, double-throw (DPDT) relay provides excellent switching capabilities. Measuring just 14x11.5x5.6mm, it is a surface-mount device (SMD) that can be easily mounted on PCBs. Its small size and SMD feature make it suitable for space-limited designs while ensuring efficient and secure operation. Count on the PANASONIC EW/AROMAT TQ2SA-12V-Z Signal Relay for efficient switching and reliable performance in your electronic projects.

Search Keywords: TQ2SA12VZ

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
TQ2SA-12V-Z
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410020
COO:
JP
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
500
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
12 V
Contact Arrangement:
DPDT
Maximum Current Rating:
2 A
Mounting:
Surface Mount
Operating Temperature:
-40 to 85 °C
Dimension:
14 x 11.5 x 5.6 mm
Termination Style:
Gull Wing
Coil Current:
11.7 mA
Contact Form:
2 Form C
  Different packaging options available.  See Alternatives

IN STOCK: 0

On Order: 4,000   can ship 7/17/26

Minimum Order Quantity: 10

Factory Lead-Time 29 Weeks

Price (USD)

Qty
Unit Price
10
$1.685
100
$0.864
250
$0.854
500
$0.837
1,000
$0.829
2,500
$0.825
5,000
$0.821
7,500 +
$0.817
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
