TQ2SS-5V by panasonic electronic components
Image is representational - see mfr. specs

TQ2SS-5V

Panasonic Electronic Components

Signal Relay 5VDC 2A DPDT(14x9.3x7.5)mm SMD ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The TQ2SS-5V is a compact surface-mount relay featuring a 2 Form C contact arrangement with a nominal coil voltage of 5 V DC. It is housed in a flat, low-profile package measuring 14.0 mm (L) × 9.0 mm (W) × 5.0 mm (H), making it ideal for space-constrained applications. The relay exhibits high sensitivity with nominal operating power of 140 mW for the 2 Form C single side stable type, outstanding surge resistance rated at 2,500 V (2×10 µs contact and coil per Telcordia standards), and low thermal electromotive force of approximately 2 µV. The surface-mount terminal design with space-saving configuration enables efficient PCB integration and reliable performance in telephone-related equipment, communications systems, and measurement devices.

Search Keywords: TQ2SS5V

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
TQ2SS-5V
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410020
COO:
JP
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
50
Relay Construction:
Non-Latching12534
AC Coil Voltage:
N/A
DC Coil Voltage:
5 V
Contact Arrangement:
DPDT12514
Maximum Current Rating:
2 A
Mounting:
Surface Mount12526
Operating Temperature:
-40 to 85 °C
Dimension:
14 x 9.3 x 7.5 mm
Termination Style:
Gull Wing12536
Coil Current:
28.1 mA
Contact Form:
2 Form C12515
  Different packaging options available.  See Alternatives
  Possible Replacement options available.  See Alternatives

IN STOCK: 1,320

Ships today, if you order in

Minimum Order Quantity: 50

Multiple: 50

Factory Lead-Time 20 Weeks
