TXD2-5V by panasonic electronic components

TXD2-5V

Panasonic Electronic Components

Signal Relay 5VDC 1A DPDT(15x7.4x8.2)mm THT ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The PANASONIC EW/AROMAT part TXD2-5V is a high-quality signal relay designed for various electronic applications. With a compact size of 15x7.4x8.2mm, this relay offers a double-pole, double-throw (DPDT) configuration. It operates on a 5V DC power supply and is capable of switching up to 1A of current. Its through-hole technology (THT) allows for easy installation and secure soldering onto electronic circuit boards. Overall, the TXD2-5V signal relay from PANASONIC EW/AROMAT is an excellent choice for reliable and efficient signal switching in your electronic projects.

Search Keywords: TXD25V

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
TXD2-5V
RoHS:
Yes
HTS:
8536410020
COO:
JP
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
40
Relay Construction:
Non-Latching
AC Coil Voltage:
N/A
DC Coil Voltage:
5 V
Contact Arrangement:
DPDT
Maximum Current Rating:
2 A
Mounting:
Through Hole
Operating Temperature:
-40 to 85 °C
Dimension:
15 x 7.4 x 8.2 mm
Termination Style:
PC Pin
Coil Current:
40 mA
Contact Form:
2 Form C

IN STOCK: 1,200

Can Ship immediately

Minimum Order: 40

Multiple: 40

Factory Lead-Time 18 Weeks

Price (CAD)

Qty
Unit Price
40
$5.896
80
$5.590
280
$5.267
520
$5.085
1,000
$4.915
2,520
$4.900
5,000
$4.869
7,520 +
$4.839
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
