TXD2-L-4.5V by panasonic electronic components
Image is representational - see mfr. specs

TXD2-L-4.5V

Panasonic Electronic Components

Signal Relay 4.5VDC 1A DPDT(15x7.4x8.2)mm THT

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

Signal Relay 4.5VDC 1A DPDT(15x7.4x8.2)mm THT

Search Keywords: TXD2L45V

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic Electronic Components
Part No:
TXD2-L-4.5V
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536410020
COO:
JP
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
40
Relay Construction:
Latching Single Coil
AC Coil Voltage:
N/A
DC Coil Voltage:
4.5 V
Contact Arrangement:
DPDT
Maximum Current Rating:
2 A
Mounting:
Through Hole
Operating Temperature:
-40 to 85 °C
Dimension:
15 x 7.4 x 8.2 mm
Termination Style:
PC Pin
Coil Current:
33.3 mA
Contact Form:
2 Form C

IN STOCK: 160

Ships today, if you order in

Minimum Order Quantity: 40

Multiple: 40

Factory Lead-Time 18 Weeks

Price (USD)

Qty
Unit Price
40
$2.91
80
$2.86
280
$2.76
520
$2.69
1,000
$2.65
2,520
$2.61
5,000
$2.56
7,520 +
$2.52
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
Please Note: Tariffs may apply for U.S. shipments
Older Equivalent
TXD2-L-4.5V-6
TXD2-L-4.5V-6
VIEW PRODUCT
