ERT-J1VG103FA by panasonic
Image is representational - see manufacturer specifications
Panasonic Authorized Distributor

ERT-J1VG103FA

The ERT-J1VG103FA is a surface-mount, multilayer NTC thermistor in a 0603 package with a nominal resistance of 10 kΩ for temperature sensing applications. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Reel Packaging
Accessories
End of Life: Final orders must be placed by 03/31/2027
Certificate of Compliance

DESCRIPTION

The ERT-J1VG103FA is a narrow tolerance multilayer NTC thermistor designed for precise temperature detection and compensation. It features a nominal resistance of 10 kΩ at 25°C with a tight tolerance of ±1%. This device is characterized by a B-value of 3435 K (±1%) between 25°C and 85°C and is housed in a 0603 EIA package. It is designed to operate reliably across a wide temperature range of -40°C to 125°C and has a rated maximum power dissipation of 100 mW. Its highly reliable monolithic structure makes it suitable for temperature compensation in mobile phones, temperature detection for CPUs, and managing battery pack temperatures.

Search Keywords: ERTJ1VG103FA

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic
Part No:
ERT-J1VG103FA
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8533408070
COO:
JP
ECCN:
EAR99
Reel Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
4000
Package Type:
Reel
Type:
NTC
Mounting:
PCB Surface Mount
Accuracy:
±1 %
Sensitivity Index:
3435 K
Thermal Time Constant:
N/A
Operating Temperature:
-40 to 125 °C
Resistance @ 25C:
10k ohm
Description of Terminals:
SMT
Thermal Coefficient:
N/A
Dimension:
1.6mm x 0.8mm x 0.8 mm
Supplier Package:
0603
End of Life:
Final orders must be placed by 03/31/2027
  End of Life: Final orders must be placed by 03/31/2027

IN STOCK: 77,000

Can Ship immediately

Minimum Order Quantity: 4000

Multiple: 4000

Factory Lead-Time 18 Weeks

Price (USD)

Qty
Unit Price
4,000
$0.0836
8,000
$0.0814
12,000
$0.0796
28,000
$0.0774
52,000
$0.0771
100,000
$0.0769
152,000
$0.0767
252,000 +
$0.0766
Reel Package
