Image is representational - see manufacturer specifications
Panasonic Authorized Distributor

ERZ-V05D391

The ERZ-V05D391 is a ZNR transient/surge absorber with a nominal varistor voltage of 390V designed for overvoltage protection. ...

View Datasheet Ask the Datasheet
RoHS Compliant
Packaging
Accessories
End of Life: Final orders must be placed by 03/31/2027
Certificate of Compliance

DESCRIPTION

The ERZ-V05D391 is a radial leaded, V-series ZNR transient/surge absorber designed to protect electronic circuits from overvoltage events. It features a nominal varistor voltage of 390V, a maximum allowable voltage of 250V ACrms or 320V DC, and a maximum clamping voltage of 675V at 5A. This compact device can handle a maximum peak surge current of 800A (8/20µs, 1 time) and has a maximum capacitance of 80 pF. It operates over a temperature range of -40°C to 85°C. Due to its specifications, it is well-suited for surge protection in telephone line applications, as well as in consumer, communication, and controller electronics.

Search Keywords: ERZV05D391

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panasonic
Part No:
ERZ-V05D391
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8533404000
COO:
JP
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
1000
Varistor Voltage:
390 V
Clamping Voltage:
675 V
Clamping Current:
5 A
Mounting:
Through Hole
Dimension:
5.4 x 10 x 7 mm
Maximum AC Voltage Rating:
250 V
Maximum DC Voltage Rating:
320 V
Maximum Surge Current:
800 A
Lead Style:
Radial
Lead Pitch:
5 mm
Tolerance Voltage:
N/A
End of Life:
Final orders must be placed by 03/31/2027
  End of Life: Final orders must be placed by 03/31/2027

IN STOCK: 0

On Order: 12,000   can ship 5/12/27

Minimum Order Quantity: 40

Factory Lead-Time 29 Weeks

Price (USD)

Qty
Unit Price
40
$0.393
100
$0.374
250
$0.267
500
$0.187
1,000 +
$0.170
