Image is representational - see mfr. specs

MUSS100-02-D_E

Pancon Connectors

2 Pin - MAS-CON HEADER - Series 100 - 2.54mm Pin Spacing - Straight - Unbreakable - Locking ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The MUSS100-02-D_E is a MAS-CON Series 100 header connector featuring a 2.54 mm pitch with 180° unbreakable construction, integrated locking mechanism, and polarization to ensure correct mating orientation. This 2-position connector is rated for 3.0 A continuous current with a maximum contact resistance of 20 mO and withstands 1000 V AC for one minute, maintaining an insulation resistance of 1000 MO minimum. The connector operates reliably across -40 °C to +105 °C and is constructed from copper alloy contacts with tin-nickel plating (gold plating available upon request) and PA66 GF insulator material rated UL94 V-0. The header is designed for wave soldering with a peak temperature of 235 ± 5 °C and is commonly used in industrial control systems, consumer electronics, and automotive applications where secure, polarized connections are required.

Search Keywords: MUSS10002DE

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Pancon Connectors
Part No:
MUSS100-02-D_E
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536908585
COO:
CN
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
500
Type:
Unshrouded Header3594
Body Orientation:
Straight3574
Gender:
HDR3578
Mounting:
Through Hole3586
Pitch:
2.54 mm
Number of Contacts:
2
Maximum Voltage Rating:
N/A
Maximum Current Rating:
3 A
Termination Method:
Solder3593
Operating Temperature:
-40 to 105 °C

IN STOCK: 3,062

Ships today, if you order in

Minimum Order Quantity: 500

Multiple: 500

Factory Lead-Time 16 Weeks

Price (USD)

Qty
Unit Price
500
$0.1454
2,500
$0.1145
5,000
$0.1083
7,500
$0.1067
25,000
$0.0900
50,000
$0.0864
100,000
$0.0862
150,000 +
$0.0860
Suppliers Standard Package
