PN18-6R-M by panduit canada
Image is representational - see mfr. specs

PN18-6R-M

Panduit Canada

Ring Terminal, 22 – 18 AWG, #6 stud size, nylon insulated, bulk package. ...

Datasheet
RoHS Compliant
Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The Panduit Canada part PN18-6R-M is a high-quality ring terminal designed for optimal electrical connections. It is suitable for use with wires ranging from 22 to 18 AWG, making it versatile and adaptable to various applications. This particular ring terminal is specifically designed to fit a #6 stud size, ensuring a secure and reliable connection. Made from durable materials, it is built to withstand the rigors of daily use and provides long-lasting performance. The terminal comes with a nylon insulation coating, providing insulation and protection against damage and electrical shock. Sold in bulk packaging, this product offers convenience for large installations or ongoing projects. Trust in the quality and reliability of Panduit Canada's PN18-6R-M ring terminal for your electrical connection needs.

Product Highlights:

  • Ring tongue design assures a secure connection in high vibration applications
  • Metal insulation grip sleeve crimps to wire insulation, providing protection to the crimp joint during high vibration applications
  • Internal barrel serrations assure good wire contact and maximum tensile strength
  • UL Flammability UL 94V-2/HB, maximum insulation temperature 221°F (105°C)
  • UL and CSA rated up to 600 V per UL 486
  • ‡UL and CSA approved tooling/product combinations.Note: Wire sizes #26 – #22 AWG, are not UL Listed or CSA Certified.

Search Keywords: PN186RM

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Panduit Canada
Part No:
PN18-6R-M
Alias/AKA:
PN18-6R-M, PN18-6R-3K
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8536904000
COO:
MX
ECCN:
EAR99
Supplier Standard Pack: This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
1000
Type:
Ring Tongue Terminal
Gender:
N/A
Tab Size:
N/A
Stud Size:
3.5 mm
Dimension:
20.3 x 6.4 mm
Wire Size:
18-22 AWG
Color:
Red
Operating Temperature:
105(Max) °C

IN STOCK: 3,000

Can Ship immediately

Minimum Order Quantity: 1000

Multiple: 1000

Factory Lead-Time 10 Weeks

Price (USD)

Qty
Unit Price
1,000
$0.3502
2,000
$0.3322
4,000
$0.3157
8,000 +
$0.2999
Suppliers Standard Package
Log in for special pricing Click for Quote Price Match Request
