CX2041NLT by pulse electronics

CX2041NLT

Pulse Electronics

XFMR,RF,SGL,RAC,1:1CT, T&R NPB ...

Datasheet
RoHS Compliant
Reel Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The Pulse Electronics CX2041NLT is a surface mount RF transformer designed for use in high frequency applications. This transformer features a single winding with a 1:1 center tap ratio, making it ideal for impedance matching and signal isolation in radio frequency circuits. Packaged in tape and reel for ease of handling and automated assembly, this transformer is a reliable and high-performance component for RF applications.

Search Keywords: CX2041NLT

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Pulse Electronics
Part No:
CX2041NLT
RoHS:
Yes
HTS:
8504312000
COO:
CN
ECCN:
EAR99
Supplier Standard Pack:  This information is provided for customers who prefer to buy in multiples of the Manufacturer’s Standard Package quantity. Minimum Order Quantities and Required Order Multiples are presented with our price and availability information.
2000
Package Type:
Reel
Lead Style:
N/A
Family:
CX
Maximum Insertion Loss:
0.6(Typ) dB
Dimension:
3.81mm x 3.81mm x 2.79mm
Impedance Ratio:
1:1CT
Maximum DCR Primary Side:
N/A
3dB Bandwidth:
0.05 to 450 MHz
Maximum DCR Secondary Side:
N/A
High Potential:
N/A
Maximum Interwinding Capacitance:
N/A

IN STOCK: 0

On Order: 4,000   can ship 2/2/26

Minimum Order: 250

Factory Lead-Time 12 Weeks

Price (CAD)

Qty
Unit Price
250
$3.017
500
$2.863
2,000
$2.788
4,000
$2.664
6,000
$2.649
8,000
$2.634
10,000
$2.618
16,000 +
$2.603
Suppliers Standard Package
Log in for special pricing
Click for Quote
Please Note: Tariffs may apply for U.S. shipments
