HX5020FNLT by pulse electronics
Image is representational - see mfr. specs

HX5020FNLT

Pulse Electronics

The HX5020FNLT is a surface-mount, 1:1 turns ratio Gigabit Ethernet transformer module that is compliant with IEEE 802.3 specifications. ...

Datasheet
RoHS Compliant
REEL Packaging
Accessories
This product is backed by Electro Sonic' Certificate of Compliance Guarantee. Rest assured you will receive the Manufacturer's Certificate of Compliance with your order. Certificate of Compliance Guarantee

DESCRIPTION

The HX5020FNLT is a surface-mount Gigabit Ethernet transformer module designed for high-speed network applications. It operates over a temperature range of -40°C to +85°C and features a minimum open circuit inductance (OCL) of 350 µH with an 8 mA DC bias. Key electrical characteristics include a 1:1 turns ratio, input-to-output isolation of 1500 VRMS, and a common mode rejection ratio of at least -50 dB from 10-100 MHz. This RoHS-compliant module meets IEEE 802.3 standards, making it a reliable component for various network interface designs.

Search Keywords: HX5020FNLT

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Pulse Electronics
Part No:
HX5020FNLT
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8517790000
COO:
CN
ECCN:
EAR99
Reel Pack: This product ships on a reel. Depending on the quantity ordered, you may receive full factory reels, cut tape (components on a strip cut from a reel), or a combination of both.
250
Package Type:
REEL
  Possible Replacement options available.  See Alternatives

IN STOCK: 10,840

Can Ship immediately

MOQ for In Stock Qty: 25

MOQ for out of Stock Qty: 125

Factory Lead-Time 12 Weeks

Price (USD)

Qty
Unit Price
25
$14.18
50
$13.29
125
$13.11
250
$12.29
375
$12.23
500 +
$12.16
Reel Package
