PE-63387NL

The PE-63387NL is a MOSFET gate drive transformer with a 1:1:1 turns ratio designed for high-isolation power applications. ...

View Datasheet Ask the Datasheet
RoHS Compliant
TRAY Packaging
Accessories
Certificate of Compliance

DESCRIPTION

The PE-63387NL is a MOSFET gate drive transformer designed to provide isolated gate drive signals in switching power supplies. It features a 1:1:1 turns ratio, a minimum inductance of 1500 µH, and a maximum leakage inductance of 4.0 µH. This transformer is rated for a high dielectric strength of 3750 VRMS between the gate and drive windings and operates over a frequency range of 20 kHz to 100 kHz. Engineered for a wide operating temperature range of -40°C to +125°C and featuring VDE approval with IEC62368-1, it is ideal for applications requiring robust safety isolation and reliable MOSFET control.

Search Keywords: PE63387NL

SPECIFICATIONS

Product Attribute
Attribute Value
Select Attribute
Products found: 0
Supplier:
Pulse Electronics
Part No:
PE-63387NL
Unit of Measure:
Per Each
RoHS:
Yes
HTS:
8504504000
COO:
CN
ECCN:
EAR99
Supplier's Standard Package: The item count, length, weight, or volume contained in the supplier’s original packaging for efficient storage, handling, and distribution.
30
Package Type:
TRAY
Maximum DCR Primary Side:
0.4 Ohm
Maximum DCR Secondary Side:
0.75 Ohm
Maximum Interwinding Capacitance:
50 pF
Family:
PE-63387
Dimension:
27.43mm x 27.69mm x 30.4811068mm
Lead Style:
PC Pin11050
High Potential:
375011049Vrms

IN STOCK: 0

On Order: 370   can ship 2/8/27

Minimum Order Quantity: 30

Multiple: 30

Factory Lead-Time 17 Weeks

Price (USD)

Qty
Unit Price
30
$7.25
60
$6.93
120
$6.73
270
$6.36
510
$6.34
1,020
$6.19
2,520 +
$5.95
Supplier's Standard Package
Log in for special pricing

Tools/3D Models

Product Guides

Product Changes
